CAF Oaris very High-speed train
Traction Motor

TMF 54-29-4

Traction Motor
Motor

TMF 54-29-4

Getriebe

CAF Oaris very High-speed train

Spain

Technical Specifications Motor

Technical Specifications Alternator

ID: TSA003101R1
P
550
kW
n
2825
min-1
U
2550
V
I
150
A
f
95
Hz
Q
1
m3 / s
Δp
1880
Pa
nmax
5816
min-1
m
870
kg
Mstart
3268
Nm
Air cooled, Forced ventilation, Open design

Technical Specifications Gearbox

ID: TSA003101R1
Gearbox type and drive setup
Motor/Gearbox connection
Gearbox/Wheel-set connection
Gear ratio
Axle load
t
Wheel diameter new / worn
mm
Max. operating speed of vehicle
km/h
Max. starting effort
kN
Nominal power
kW
Total weight incl. couplings
kg
Suitable for traction motor
